Sungrow 10.0kW - 1 Phase Hybrid Inverter (SH10RS)

Datasheet: SH10RS

Warranty: SG10RS

Includes

• 1 x SH10RS Inverter

Type of Inverter and Performance

The SH10RS is an advanced single-phase residential hybrid inverter tailored for efficient solar energy management in larger home setups. This model stands out with its hybrid capability, which facilitates direct connectivity to battery storage systems, a crucial attribute for homeowners who wish to optimize their solar energy usage and maintain energy independence during grid outages.

Featuring a peak efficiency of 98.3%, the SH10RS excels in converting a high percentage of solar energy into usable power, thereby enhancing the efficiency and economic return of home solar systems. It is equipped with three Maximum Power Point Trackers (MPPTs), which significantly improve the energy harvest from solar panels, especially in configurations with varied orientations or those facing intermittent shading conditions.

Safety and Reliability

Safety is paramount with the SH10RS, which includes comprehensive protective measures such as an arc fault circuit interrupter (AFCI), DC reverse polarity protection, and AC short-circuit and leakage current protection. The inverter also features integrated Type II surge protection on both DC and AC inputs to safeguard against potential voltage spikes.

Additionally, the Potential Induced Degradation (PID) recovery function is particularly noteworthy, helping to maintain and restore the efficiency of solar panels that may suffer from long-term exposure to high voltages, thereby extending their operational lifespan and maintaining performance levels.

User-Friendly Operation and Monitoring

The SH10RS supports extensive monitoring capabilities through the iSolarCloud platform, which updates in real-time to provide detailed insights into system performance and energy production. Its user-friendly interface, accessible through both web and mobile applications, allows homeowners to easily track and control their energy consumption.

Designed for straightforward installation, the SH10RS features plug-and-play connectors and compact dimensions, making it both space-efficient and easy to incorporate into existing or new home energy systems. It also offers diverse communication options, including Ethernet, WLAN, and RS485, ensuring high compatibility with various home automation and intelligent energy systems.

Battery Compatibility

This inverter ensures seamless integration with energy storage solutions, supporting a broad range of lithium-ion batteries. Its supported voltage range from 120V to 550V enables homeowners to customise their energy storage setup based on their specific needs, enhancing system flexibility and performance.

Warranty and Support

The SH10RS is backed by a robust ten-year warranty that covers material and workmanship defects, providing homeowners with confidence and assurance of the inverter's quality. This warranty ensures that any parts found to be faulty under normal operational conditions are repaired or replaced. With Sungrow’s dedicated support and comprehensive warranty terms, users are guaranteed prompt assistance and extensive coverage for their investment, making the SH10.0RS a reliable and efficient choice for residential solar energy solutions.
